AC-300™ Acrylic is a plastic sheet product designed to control static electricity for a wide range of end uses. It is a premium quality acrylic sheet which has been surfaced with a clear C-300™ static dissipative surfacing. This unique technology prevents charge generation on the sheet surfaces, thereby controlling particulate attraction and preventing electrostatic discharge (ESD) events. This performance is permanent and totally independent of humidity. AC-300™ Acrylic offers exceptional design versatility since it fabricates simply, is light in weight and is available in large sheet sizes. AC-300™ also exhibits excellent optical properties, chemical resistance, surface hardness and mar / scratch resistance.

AC-300™ Acrylic is easily fabricated into flat surface configurations using the same equipment and fabrication techniques generally employed with unsurfaced acrylic sheet products. It should not be used for heat formed bent configurations since the hard, cured C-300™ surface is not designed for heat bending. When solvent welding, it is necessary to remove the C-300™ surface mechanically to achieve a good bond.

Do you need Fabrication or Machining for AC 300 Static Dissapative Acrylic?

Contact us today for your fabrication and machining needs!

Request Fabrication/Machining Services
At a Glance

Generic Name
Acrylic

Available In
Sheet

Certifications
ITAR Registered

Start Your Quote

Send us a message:

*Required Fields

Gallery

Technical Information

Stock Products Properties Applications Advantages Grades

Stock Products

TypeSizeLengthColor
Sheet 1/8″ – 1/2″ 48” x 96” CTS Clear & Transparent Grey & Bronze tint, Other colors available on special order

Give us your cut-to-size dimensions. We will precision-cut these plastics to your exact size. Additional sizes and colors available upon request.

Properties

Physical PropertiesUnitsASTMResults
Density g/cm^3 D792 1.19
Mechanical PropertiesUnitsASTMResults
Tensile Strength @ yield psi D638 10000
Tensile Modulus MPa D638 400000
Tensile Elongation @Break % D638 4.2
Flexural Strength MPa 16500
Flexural Modulus psi 475000
Compressive Strength psi D695 18000
IZOD Impact Strength Notched kJ.m^2 D256 0.4
Thermal PropertiesUnitsASTMResults
Coeffcient of Linear Thermal Expansion x10^-5/K C177 3.5
Heat Deflection Temp at 264 psi °F 210
Electrical PropertiesUnitsASTMResults
Surface Resistivity @60 Hz ohms/sq D257 10^6
Volume Resistivity, 50% RH ohm-cm D250 10^5
Optical PropertiesUnitsASTMResults
3mm Transparent Clear Transmittance. Total (%) % D1003 80
Refractive Index % D542 1.48 – 1.50

Applications

  • Covers
  • Windows
  • Doors
  • Access panels for electronic equipment
  • Semi-conductor
  • Electronic equipment
  • Micro-manufacturing
  • Fabricated desiccators
  • Cabinets & boxes
  • Process equipment enclosures

Advantages

  • Prevents buildup of static charge & accumulation of harmful contamination
  • Cannot be tribocharged when properly grounded
  • Electrostatic decay is less than .05 second per Federal Test 101C, Method 4046.1
  • Results in rapid static dissipation without arching
  • Provides for ESD control without the need for ionization
  • Avoids conductive discontinuities
  • Provides excellent shatter resistance for safety
  • Excellent clarity
  • Superior chemical resistance
  • Superior fabricating properties

Grades

  • AC-350™ Static Dissipative Acrylic (Bending Grade)
